Glycol Coolers
| TECHNICAL SPECIFICATIONS | KALINKA ICE |
KALINKA V-ICE |
TAYFUN T75G/ H35G(VP) |
TAYFUN T75G/ H35G(GP) |
LCB3500, 200FT |
EXTRA 1/2 | EXTRA 3/4 | EXTRA 1 ½ | V-200G |
|---|---|---|---|---|---|---|---|---|---|
| Part number | KG-1/6T | KVG-1/6T | T75G-1/3T/ H35G-1/3T |
T75G-1/3P/ H35G-1/3P |
LG3500-1/2P | EG-1/2P | EG-3/4P | EG-1/2P | V-200G |
| Maximum distance, ft | 25’ | 25’ | 75’/75’ | 125’/125’ | 200’ | up to 250’ | up to 450’ | up to 750’ | 30 |
| Capacity, BTU/hr evap 20f | 1150 | 1150 | 2600/2600 | 2600/2600 | 3500 | 3900 | 5500 | 10800 | 6121 |
| Glycol tank capacity, gal | 2 | 2 | 5 | 5 | 2 | 15 | 15 | 18 | 18 |
| Dedicated circuit, A | 10 | 10 | 15/15 | 15/15 | 20 | 20 | 20 | 20 | 10 |
| Compressor power, HP | 1/6 | 1/6 | 1/3 / 1/3 | 1/3 / 1/3 | 1/2 | 1/2 | 3/4 | 1½ | 1 |
| Pump type | Totton SPC42-90W |
Totton SPC42- 90W |
Totton SPC42- 90W |
Procon-100 gal/ hr |
Procon-100/ gal/hr | Procon -100/ gal/hr | Procon -100/ gal/hr | Procon -100/ gal/hr | Fluid-o- Tech 75 gal/hr |
| Optional additional pump | --- | --- | --- | --- | --- | Procon -100/ gal/hr | Procon -100/ gal/hr | Procon -100/ gal/hr | Fluid-o- Tech 75 gal/hr |
| Refrigerant | R 134a R 290 |
R 134a R 290 |
R 134a | R 134a | R 134a | R 134a | R 134a | R 134a | R 134a |
| Width, in | 17 | 11,19 | 15/27 | 15/27 | 13 | 20 | 20 | 29 | 23,5 |
| Depth, in | 19 | 17,03 | 15/18 | 15/18 | 18 | 25 | 25 | 23 | 23,5 |
| Height, in | 17 | 23,24 | 30/19 | 30/19 | 28 | 32 | 32 | 32 | 41,5 |
